ZHF Technology Services. It has helped numerous companies to meet their goals of designing/developing products, prototypes, & general PCB assembly.

Our Services

FPGA Development

Full lifecycle development for Xilinx, Intel, and Lattice platforms, including RTL design, verification, and timing closure.

ASIC Design

Custom ASIC solutions from specification to GDSII including DFT, power analysis, and physical verification.

Verification

Comprehensive verification using UVM, formal methods, FPGA prototyping, and coverage-driven methodologies.

RISC-V Solutions

Custom RISC-V cores, SoC integration, and verification for applications from embedded to high-performance computing.

RISC-V Expertise

We specialize in complete RISC-V based solutions from core microarchitecture to full SoC implementation and verification.

Core Development

  • Custom RISC-V core design (32/64-bit)
  • RV32I/E, RV64I, M, A, F, D, C extensions
  • Vector processing (V extension)
  • Custom instruction extensions
  • Multi-core implementations
  • Cache coherency solutions
  • Power-optimized designs

Verification

  • RISCV-DV based verification
  • Formal verification of core correctness
  • UVM-based testbenches
  • Coverage-driven verification
  • FPGA-based emulation
  • Performance benchmarking
  • Security verification

SoC Integration

  • AMBA/AXI interconnect
  • Memory subsystem design
  • Peripheral integration (UART, SPI, I2C)
  • DMA controller integration
  • Security subsystems
  • Power management units
  • Debug interface (JTAG, Trace)

Software Ecosystem

  • Custom toolchain support
  • Bare-metal firmware
  • RTOS porting (FreeRTOS, Zephyr)
  • Linux BSP development
  • Bootloader customization
  • Security stack implementation
  • Performance optimization

Customized RISC-V SoC Architecture

Core Complex

  • RISC-V CPU Core(s)
  • L1/L2 Cache
  • FPU/Vector Unit
  • Debug Module

Memory

  • SRAM/ROM
  • DDR Controller
  • Flash Controller
  • DMA Engine

Interconnect

  • AXI/AHB Interconnect
  • Peripheral Bus
  • Network-on-Chip

Peripherals

  • Timers/Counters
  • UART/SPI/I2C
  • GPIO
  • Ethernet/USB

RISC-V Implementation Options

FPGA Implementation

  • Xilinx/Intel FPGA optimized cores
  • High-frequency designs
  • Custom acceleration
  • Rapid prototyping

ASIC Implementation

  • Process nodes from 180nm to 5nm
  • Power-performance optimization
  • DFT insertion
  • Signoff verification

Verification Solutions

  • RISCV-DV compliance tests
  • Formal property verification
  • FPGA prototyping
  • Performance analysis
